Low dew point dehumidifiers are not your typical humidity control devices. They are tailored to meet the specific needs of environments where maintaining a bone-dry atmosphere is a necessity. These environments range from research laboratories to data centers and storage facilities for sensitive materials.
| Quantity: | |
|---|---|
Unlike universal refrigerated dehumidifiers or general industrial desiccant units that lose efficiency in ultra-low humidity environments, this system is a specialized dehumidification solution developed solely for lithium battery production workflows. It adopts a high-performance silica gel-molecular sieve composite desiccant rotor, paired with a multi-stage refrigeration and deep adsorption composite process, overcoming the industry-wide pain point of sharp efficiency drops and unstable dew point in low-humidity conditions.
The system is fully compatible with the entire lithium battery production chain, from raw material storage, electrode mixing, coating and rolling, to cell assembly, electrolyte injection, formation and aging. It provides a one-stop, fully customizable humidity control solution for lithium battery manufacturers, new energy production facilities, and industrial plant managers, supporting both greenfield production line planning and existing line retrofitting while meeting global industry compliance and safety standards.
The system follows a closed-loop, multi-stage dehumidification workflow optimized for the extreme dryness needs of battery production:
Air Intake & Pre-Treatment: Ambient air enters the system and first passes through a multi-stage pre-filtration unit, which removes large particulate matter, dust, and electrode powder from the air, protecting internal core components and meeting the cleanliness requirements of battery production workshops.
Pre-Cooling & Preliminary Dehumidification: The filtered air is cooled by a high-efficiency refrigeration system to condense and remove most of the moisture, reducing the load on the subsequent desiccant adsorption stage and improving overall energy efficiency.
Deep Desiccant Rotor Adsorption: The pre-treated air passes through the rotating composite desiccant rotor, where residual water vapor is intensively adsorbed by the molecular sieve and silica gel material, achieving the ultra-low dew point required for battery production.
Regeneration & Closed-Loop Operation: A small stream of regeneration air is heated to desorb the moisture captured in the rotor, which is then discharged outside the system. This continuous cycle ensures long-term stable dehumidification performance without frequent manual intervention.
Post-Treatment & Precision Control: The dried air undergoes fine temperature and humidity adjustment via the post-treatment unit, ensuring the air delivered to the workshop maintains a constant dew point and temperature, even under fluctuating ambient conditions.
Every core component is selected for industrial-grade durability and stable performance in 24/7 continuous production environments, delivering tangible value for battery manufacturing facilities:
High-Efficiency Composite Desiccant Rotor: The core adsorption component, combining molecular sieve and high-performance silica gel, maintains over 95% adsorption efficiency even in ultra-low humidity environments, with a service life 30% longer than standard single-material rotors, reducing replacement and maintenance costs for production facilities.
Three-Stage Filtration System: Equipped with primary, medium, and high-efficiency filters, it effectively removes airborne particulate matter and electrode powder, preventing contamination of battery materials while protecting the rotor from abrasion, extending equipment maintenance cycles.
Precision PLC Control System: With a touchscreen human-machine interface, it monitors dew point, temperature, and humidity in real time, automatically adjusting operating parameters to match the needs of different production stages. It supports integration with the factory’s central automation system, enabling unattended operation and reducing labor input for plant managers.
Energy-Saving Waste Heat Recovery Unit: Recovers waste heat from the regeneration air heating process to pre-heat incoming regeneration air, reducing overall energy consumption by 15-25% compared to similar standard rotary dehumidifiers, lowering long-term utility costs for industrial clients.
The system maintains a stable adjustable dew point range of -40℃ to -80℃, with a dew point fluctuation of ≤±2℃ even under extreme ambient temperature and humidity changes. It completely eliminates the risk of exothermic reactions, battery swelling, and thermal runaway caused by contact between lithium materials and moisture, fundamentally improving the intrinsic safety of the battery production process and reducing safety management risks for manufacturers.
Precise, constant humidity control eliminates production defects caused by humidity fluctuations, including uneven electrode coating, poor electrolyte infiltration, and degraded active material performance. Field verification from client applications shows that the system can increase cell production yield by 3-8%, while ensuring consistent performance across mass production batches, reducing scrap losses and rework costs for battery producers.
We provide fully customized dehumidification solutions based on your specific production needs, including workshop size, production capacity, target dew point, and existing line layout. Whether you are building a new battery production facility, retrofitting an existing dry room, or upgrading a single production stage, our system can be tailored to fit your operations without requiring extensive modifications to your existing workflow.
Built for 24/7 continuous industrial operation, the system uses heavy-duty industrial components with a mean time between failures (MTBF) of over 8000 hours. It is equipped with multiple safety protection features, including overload protection, overheating protection, and fault alarm functions, minimizing unplanned downtime and production interruptions that cause significant revenue losses for manufacturing facilities.
Maintains a stable dew point of -40℃ to -50℃, preventing moisture absorption by the electrode slurry during coating and drying, ensuring uniform coating thickness and consistent active material performance, and reducing the risk of electrode cracking and peeling.
Delivers a reliable dew point of -50℃ to -60℃, creating a strictly controlled dry environment for cell winding, lamination, and tab welding processes, avoiding moisture contamination of bare cells and ensuring the structural integrity of the battery core.
Provides an industry-leading stable dew point of -60℃ to -80℃, meeting the most stringent dryness requirements for electrolyte injection. It prevents moisture from mixing with the electrolyte, which can cause gas generation, capacity decay, and shortened cycle life of the finished battery.
Maintains constant low humidity conditions for the storage of lithium salts, electrode materials, and electrolytes, preventing raw material degradation and moisture absorption before production, ensuring the consistency of incoming materials and reducing waste from spoiled raw materials.
Controls ambient humidity during the battery formation and aging process, preventing moisture from corroding battery terminals and test equipment, ensuring the accuracy of formation test data, and reducing the risk of short circuits during the final testing stage.
Parameter | Standard Configuration Range | Customization Support |
Process Air Flow | 1000 m³/h – 50000 m³/h | Fully customizable based on workshop size and production capacity |
Achievable Dew Point | -40℃ ~ -80℃ | Adjustable to meet specific process requirements |
Rated Power | 3.5 kW – 180 kW | Optimized based on air flow and dew point requirements |
Operating Voltage | 380V/3Ph/50Hz (Standard) | Customizable for 220V/440V, 60Hz power supply |
Regeneration Temperature | 100℃ – 140℃ | Adjustable for energy efficiency optimization |
Filtration Grade | Primary + Medium + HEPA H13 | Upgradable to higher filtration grades for ultra-clean workshops |
Control Mode | PLC + Touchscreen HMI | Support for MODBUS, Profinet communication, factory central control integration |
Ambient Operating Temperature | -10℃ ~ 45℃ | Customizable for extreme ambient conditions |
All our lithium battery dedicated rotary dehumidifiers comply with global industrial safety and quality standards, with full CE, ISO 9001, UL, and RoHS certifications. Every unit undergoes strict 72-hour continuous operation testing and dew point stability verification before delivery, ensuring it meets the specified performance parameters when it arrives at your facility.
We use only internationally recognized industrial-grade brands for core components, including compressors, motors, and control systems, to ensure long-term stable operation. Our quality management system covers the entire product lifecycle, from design and manufacturing to on-site commissioning and after-sales support, giving industrial clients full peace of mind for their production operations.
Dew point requirements vary by production stage: electrode coating and drying typically require -40℃ to -50℃, cell assembly needs -50℃ to -60℃, and electrolyte injection processes demand the strictest dew point of -60℃ to -80℃. Our system can be fully customized to meet the specific dew point needs of each stage of your production line.
Standard refrigerated dehumidifiers can only achieve a dew point of around 10℃, and their efficiency drops sharply in low-humidity environments, making them unable to meet the ultra-low dew point requirements of lithium battery production. Our rotary desiccant dehumidifier uses physical adsorption to remove moisture, reliably achieving and maintaining the -40℃ to -80℃ ultra-low dew point needed to ensure battery safety, performance, and production yield.
Yes, we specialize in providing retrofittable solutions for existing production lines. Our engineering team will conduct on-site assessments of your existing workshop layout, production process, and humidity control needs, designing a fully customized system that integrates seamlessly with your current operations without requiring extensive production downtime or line modifications.
