The characteristics of isosorbitol device cold storage dedicated low humidity dehumidifier:
According to the working principles and process characteristics of various batteries, the production of certain batteries must be carried out in extremely dry environments, such as lithium batteries, lithium-ion batteries, thermal batteries, and lithium materials. Therefore, low dew point dehumidifier is indispensable in the production of these batteries and materials, as the effectiveness of dehumidifier and drying directly impacts the electrical performance and safety of the batteries. The low dew point dehumidifier have been tested over many years in the above production processes and have proven to fully meet the requirements of these production processes. They are now widely used in the lithium battery industry and various other applications requiring low dew points.
The ZHL series dehumidifiers mainly consist of a compression condensing unit (or centralized chilled water supply), a direct evaporative heat exchanger or water-cooled heat exchanger, a super silica gel or molecular sieve rotor assembly, and a microcomputer control system.
Technical parameters of isosorbitol device cold storage dedicated low humidity dehumidifier :
| Main Parameters / Model | ZHL-9000 | ZHL-12000 | ZHL-15000 | ||
| Process Air | Airflow m³/h | 9000 | 12000 | 15000 | |
| Fan Power kW | 11 | 11 | 15 | ||
| Regeneration Air | Airflow m³/h | 2250 | 3000 | 3750 | |
| Fan Power kW | 2.2 | 2.2 | 3 | ||
| Regeneration Mode | Electrical Heating Power kW | 72 | 96 | 120 | |
| Steam Consumption kg/h | 120 | 160 | 200 | ||
| Drive Motor Power kW | 0.27 | 0.34 | 0.37 | ||
| Attemperation Electrical Heating Power kW | 18 | 24 | 24 | ||
| Outlet Air | Temperature °C | 20-25 | |||
| Relative Humidity % | ≤-60 | ||||
| Supporting System Refrigerating Capacity kW | 142 | 189 | 236 | ||
| Installed Power | Electrical Heating kW | 103.47 | 133.54 | 162.37 | |
| Steam Heating kW | 31.47 | 37.54 | 42.37 | ||
| Overall Dimensions | Length mm | 6000 | 6400 | 6800 | |
| Width mm | 1980 | 2180 | 2380 | ||
| Height mm | 3250 | 3350 | 3450 | ||
| Weight kg | 3500 | 4200 | 5000 | ||
Note:
1. Leakage air volume is calculated by 10% of process air volume.
2. The ratio of fresh air is 10% of air output.
3. Output air excess pressure 300Pa
4. Process fan adopt unhoused fan with inverter.
Process flow chart of isosorbitol device cold storage dedicated low humidity dehumidifier:
Application of isosorbitol device cold storage dedicated low humidity dehumidifier:
Humidity Control: The production and storage of isosorbide have strict requirements for environmental humidity. Excessive humidity may lead to a decline in product quality or equipment corrosion. Rotary dehumidifiers can effectively reduce humidity inside the cold storage, ensuring that the environmental humidity remains stable within the required process range.
Improving Product Quality: Isosorbide is a humidity-sensitive substance. Excessive humidity may cause it to absorb moisture, clump, or undergo chemical reactions. Through precise humidity control by rotary dehumidifiers, these issues can be avoided, ensuring product stability and quality.
Extending Equipment Lifespan: Equipment in cold storage is prone to rust or corrosion in humid environments. Rotary dehumidifiers reduce humidity, thereby minimizing the risk of equipment corrosion and extending the service life of the equipment.
Energy Efficiency: Rotary dehumidifiers utilize efficient dehumidification technology, enabling stable operation in low-temperature environments with low energy consumption. This makes them suitable for the long-term needs of cold storage.
Automated Control: Modern rotary dehumidifiers are typically equipped with intelligent control systems that can automatically adjust operation based on humidity changes in the cold storage, achieving precise humidity control and reducing the need for manual intervention.
In summary, the application of rotary dehumidifiers in the cold storage of isosorbide production facilities not only effectively controls humidity but also improves product quality, extends equipment lifespan, and achieves energy-efficient operation. They are an indispensable key component in the production and storage processes of isosorbide.
FAQ:
Q: What’s MOQ?
A: one set.
Q: What’s delivery?
A: Within 35 days after receipt of down payment.
Q: What’s package?
A: Wooden cases,a kind of standard package for export.We could also make special package according to your demand.
Q: What’s payment terms?
A: TT or L/C
Q: Customized service?
A: We offer OEM/ODM service.
